Wire Mesh Common Unit Converter - Fast and Efficient
Quickly convert common units of length, weight, area, volume, porosity and more with Us free online tool.
Unit Conversion Tool
Square Grid Opening Calculator (mm)
Parameter Explanation:
- Mesh Size: Distance between the centers of two adjacent wires (includes wire diameter)
- Wire Diameter: Diameter of the wire material
- Open Area: Net flow area of a single grid opening
- Total Area: Total area of a single grid unit (including wire material)
Calculations provided by DuoZhuang | www.metalmeshfiltration.com
Filter Precision Calculator
Material
Weave Type
Warp Wire Diameter (ds)
Weft Wire Diameter (dk)
Mesh Count (Warp)
Mesh Count (Weft)
Weave Factor
Reverse Factor (for Reverse Dutch)
Output Unit
Theoretical Filter Precision
μm
Open Area Ratio
%
Wire Area Ratio
%
Mesh Weight
kg/m²
Parameter Explanation:
- Warp Wire: The wire running lengthwise in the mesh
- Weft Wire: The wire running crosswise in the mesh
- Mesh Count: Number of wires per linear inch or centimeter
- Weave Factor: Adjustment for weave type and wire arrangement
- Reverse Factor: Adjustment factor for reverse dutch weave structure
Calculation Methods:
- Plain Weave: Precision = min((1/Mesh - Wire Diameter) × 1000)
- Dutch Weave: Precision = (1/Mesh - Wire Diameter) × Weave Factor × 1000
- Reverse Dutch Weave: Precision = [(1/Mesh - Wire Diameter) × Weave Factor × Reverse Factor] × 1000
- Open Area: (Aperture Warp × Aperture Weft) / (1/Mesh Warp × 1/Mesh Weft) × 100%
© DuoZhuang | www.metalmeshfiltration.com
-
